Electrical wire anchor winch
2.210 kg on layer 1 / 1.047 kg on layer 6
Holdingforce 11.500 kg on layer 1
Applicable for 2x anchors till 770 kg
3x drums ø 180 x 280 mm (1 executed as fiberrope drum, Dyneema)
cable capacity 3x 69 meter cable ø 22 mm on 7 layers + 3 safetywindings
400V 50Hz 3ph (IP56)
T1 – L3 – M2 (according FEM 1.001 en ISO 4301/1)
Usertemp. -10° tot +40° Celsius
3x manual bandbrake with stainless steel spindle
3x manual clutch with stainles steel handle
2x capstanhead ø 258 mm
Surface treatment transmission and drums: 3- layer RAL5010, remaining parts ZnNi treatment
Also available with cables, winchcontrols and electrical anchor drop
Inlandshipping
